F4 or F7 processing
Choose the F4 for light builds or the F7 for extra UARTs, blackbox and filtering headroom.
F4/F7 AIO FC + 4-in-1 ESC
AIO Flight Stack
One board, the whole power system — Betaflight, no Remote ID
The AIO Flight Stack combines an F4 or F7 flight controller and a 4-in-1 electronic speed controller on a single board, in 20×20 mm or 25.5×25.5 mm mounts, rated for 4S to 6S. It ships running open-source Betaflight firmware with no Remote ID module, giving builders full PID and filter control out of the box.
- Free global shipping
- On-site training
- 1-year care plan
- 6S Max cell count
- 55A ESC continuous per channel
- 2sizes 20×20 / 25.5×25.5
- 0RemoteID No module built in
Why choose the AIO Flight Stack
One platform, every mission
4-in-1 ESC, 55A
Integrated four-channel ESC rated to 6S continuous — fewer wires, cleaner builds, easier repairs.
Betaflight, open
Runs stock Betaflight with presets ready; flash, tune and fly with no vendor lock-in.
No Remote ID
Ships without a Remote ID module, so you keep full firmware freedom for non-regulated use cases.
Missions
Ready for every deployment
01
Build
Clean first build
AIO means one board instead of a separate FC and ESC — less weight, fewer failure points.
Start this mission
02
Tune
Dial in the tune
Plug into Betaflight Configurator and shape PID, filters and rates in minutes.
Start this missionTechnical details
Specifications
Flight controller
| MCU | F4 / F7 selectable |
|---|---|
| Gyro | BMI270 / ICM42688 |
| Mount | 20×20 / 25.5×25.5 mm |
| OSD | Onboard Betaflight OSD |
| Blackbox | Onboard SPI flash |
ESC
| Type | 4-in-1 BLHeli_32 / AM32 |
|---|---|
| Current | 45–55 A continuous |
| Cells | 4S–6S LiPo |
| Protocol | DSHOT600 |
From our customers
Reviews
★★★★★
“Cleanest AIO I have used. Soldered once, configured in Betaflight, and it just flies. No Remote ID nonsense.”
★★★★☆
“Sells fast. The 25.5×25.5 version is perfect for Cinewhoop frames in this category.”
Ready for your mission
One board, total control.
Trust your most critical missions to the most dependable platform.
Configure your AIO Flight StackChoose your kit
Buy the AIO Flight Stack
Before you buy
FAQ
F4 or F7 — which do I need?
F4 is enough for most 3–3.5 inch whoops. Pick F7 if you want more UARTs for GPS, LEDs or a second receiver.
Is Remote ID included?
No. The stack ships without a Remote ID module, matching the spec you requested for unrestricted firmware use.
What motors pair with it?
Our 1404, 1507, 2004 and 2006 brushless motors in this category are a direct match for 4S–6S setups.
